Getting started with the Windows Sandbox

Scott Lester
7 September 2022
|
4 min Read
|
Scott Lester

Want to see where that dodgy link goes, install a temporary application or inspect a suspicious file? If you’re on Windows, if you enable the Sandbox it’s the perfect tool.

What is it?

Windows Sandbox is a convenient, pre-installed and licenced virtualised version of Windows. You can launch it, do what you want, and when you close it it’s all gone:

As the documentation says:

Windows Sandbox provides a lightweight desktop environment to safely run applications in isolation. Software installed inside the Windows Sandbox environment remains “sandboxed” and runs separately from the host machine.

A sandbox is temporary. When it’s closed, all the software and files and the state are deleted. You get a brand-new instance of the sandbox every time you open the application.

Microsoft overview

What’s it for?

Well, anything really. But given its ephemeral nature, it’s very well suited to temporary tasks where you don’t want to affect your main computer. Think installing some application to test it or use it once, or inspecting unusual or suspicious links and documents.

Getting Started

As Microsoft article states, you need to be on “Windows 10 Pro, Enterprise or Education build 18305 or Windows 11”, so not Windows 10 Home, for example. If you one of the supported versions, and have virtualisation enabled, it’s pretty straight forward to install; you just need to enable it as a Windows feature.

See this good guide for step-by-step instructions.

Note that if you’re using VMWare to run other Virtual Machines, Sandbox (and Hyper-V) may conflict.

After it’s enabled, you can just run it from the Start Menu:

That launches the vanilla Sandbox, which is fine for a lot of things. Even better though: you can specify a configuration file to launch a custom sandbox.

Configuration Files

Sandbox configuration files are in XML, and should be saved with the .wsb extension. They can then be double-clicked to launch a sandbox in that configuration. The configuration files support a range of options and keywords. As listed in this Microsoft page, there are a few optional keywords of particular interest:

Keyword Options
vGPU Enable or disable hardware GPU sharing
Networking Enables or disables networking
MappedFolders An array of folders mapped from the host to the sandbox, in absolute paths only
LogonCommand Specifies a single command that will be invoked automatically after the sandbox logs on
ProtectedClient Applies additional security settings to the sandbox Remote Desktop client
ClipboardRedirection Enables or disables sharing of the host clipboard with the sandbox

Other options allow for enabling or disabling the audio and video, redirecting printers and other things.

Networking

For example, you can use a Networking entry to disable networking on the sandbox:

<Configuration>
    <Networking>Disable</Networking>
</Configuration>

This is useful for examining suspicious files, where you want to deny network access to the whole virtual environment.

Mapped Folders

You can use the configuration file to map a local folder into the sandbox, and optionally make it read-only. For example, if we want to map a couple of local folders:

<MappedFolders>
   <MappedFolder>
     <HostFolder>C:\Users\scott\Work\windows\win_sandbox\share</HostFolder>
     <ReadOnly>false</ReadOnly>
   </MappedFolder>
   <MappedFolder>
     <HostFolder>C:\Users\scott\Work\windows\win_sandbox\install</HostFolder>
     <ReadOnly>true</ReadOnly>
   </MappedFolder>
</MappedFolders>

We get them on the desktop in the sandbox:

In this case, we’ve got the share folder to sync files between the sandbox and the host, and an install folder to map some installers, some custom binaries, and a couple of configuration scripts to run in the sandbox. Talking of which…

Auto-configuration

In the wsb configuration file you can use LogonCommand to run a script. For example, if we first map a folder into the sandbox (in this case read-only):

<MappedFolder>
    <HostFolder>C:\Users\scott\Work\windows\win_sandbox\install</HostFolder>
    <ReadOnly>true</ReadOnly>
</MappedFolder>

We can call that script automatically when the sandbox logon is complete:

<LogonCommand>
    <Command>C:\Users\WDAGUtilityAccount\Desktop\install\install.bat</Command>
</LogonCommand>

The script we’re using does four things, which is a nice example:

REM Download Visual Studio Code (we could of course download a static version and put it in a mapped folder)
curl -L "https://update.code.visualstudio.com/latest/win32-x64-user/stable" --output C:\users\WDAGUtilityAccount\Desktop\vscode.exe

REM Install and run Visual Studio Code
C:\users\WDAGUtilityAccount\Desktop\vscode.exe /verysilent /suppressmsgboxes

REM Install HxD hex editor
start /wait C:\Users\WDAGUtilityAccount\Desktop\install\HxDSetup.exe /quiet /norestart

REM allow scripts in powershell
powershell.exe -noexit Set-ExecutionPolicy -ExecutionPolicy Unrestricted -Force

REM run powershell script to show file extensions, do other config
powershell.exe -noexit C:\Users\WDAGUtilityAccount\Desktop\install\config.ps1

You have to be a little patient to wait for it to complete, but when it does we have a nice, useful sandbox:
